TPUHose™ Series

TPUHose™ Series

General TPU Layflat Hose for Water Transfer & Industrial Applications
TPUHose™ Series

The TPUHose™ Series is Yoonad Hose's core range of TPU layflat hoses  designed for general fluid transfer across demanding industrial and municipal  applications. Manufactured with high-strength TPU lining and woven  reinforcement, TPUHose™ products offer excellent abrasion resistance,  flexibility, lightweight handling, and long service life compared with  conventional rubber or PVC hoses. The series is widely used for long-distance  water transfer, temporary bypass pipelines, agricultural irrigation, mining  dewatering, slurry transport, municipal water supply, emergency pumping,  firefighting, and flood control projects. Available in multiple pressure ratings  and diameters, TPUHose™ provides reliable performance under continuous  field operation while reducing transportation and installation costs.

contact us
TPUHose™ Series
TPUHose™ Series
TPUHose™ Series
TPUHose™ Series
TPUHose™ Series
TPUHose™ Series

Specifications

Size: 1"- 24"

Standard Color: other colors available upon request

Length: Up to 400m,  (customized lengths available)

Application: Dewatering

Advantages: High-pressure performance, Corrosion-resistant, Highly abrasion-resistant, Lightweight and portable, High tensile strength


Structure

Inner Tube: Thermoplastic Polyurethane (TPU)

Outer Cover: Thermoplastic Polyurethane (TPU)

Reinforcement: Circular-woven polyester jacket

Operating Temperature Range:  -60°F to 176°F (-50°C to 80°C)

Data Sheet

Part No.IDThicknessWeightWorking pressureBursting pressureTensile Strength
Inchmmmmkg/mPSI/barPSI/barKG
YTPU1501-1/2"39+1.52.60.45300/21900/635800
YTPU2002"51+1.53.00.70300/21900/635800
YTPU2502-1/2"64.5+2.03.00.75300/21900/636100
YTPU3003"76+2.03.01.07250/17750/519900
YTPU4004"104+2.03.51.45250/17750/5118200
YTPU6006"155+2.04.02.30200/14600/4227100
YTPU8008"205+3.04.53.50215/15645/4545800
YTPU100010"254+3.04.23.80200/14600/4257800
YTPU120012"305+3.04.34.60200/14600/4278300
YTPU140014"355+3.04.35.25200/14600/4292100
YTPU160016"405+3.04.36.20150/10450/30101800


faqs

What is TPUHose™ used for?
TPUHose™ is designed for general industrial water transfer and fluid handling. It is commonly used for agricultural irrigation, mining dewatering, municipal water supply, flood control, temporary bypass pipelines, and emergency pumping.
Why choose a TPU layflat hose instead of a PVC or rubber hose?
Compared with PVC and rubber hoses, TPU layflat hoses are lighter, more flexible, more abrasion resistant, and typically have a longer service life. They also reduce transportation, installation, and maintenance costs.
What fluids can TPUHose™ transfer?
TPUHose™ is primarily designed for clean water, industrial water, wastewater, slurry, and other non-corrosive fluids. Media compatibility should always be confirmed before use.
What industries use TPUHose™?
Typical industries include: • Municipal water supply • Agriculture • Mining • Construction • Flood control • Emergency response • Water transfer projects
What pressure ratings and sizes are available?
TPUHose™ is available in multiple diameters and working pressure ratings. Custom sizes and pressure classes can also be manufactured based on project requirements.
Can TPUHose™ be used outdoors?
Yes. TPUHose™ offers excellent resistance to abrasion, UV exposure, weathering, and repeated field deployment, making it suitable for long-term outdoor use.
How do I choose the correct TPUHose™ model?
Selection depends on: • Flow rate • Working pressure • Hose diameter • Transfer distance • Operating environment • Fluid type

* TPUHose™, Hosewear™, Terkon™, Sanvive™, and Frigari™ are trademarks registered by Yoonad Group in the People's Republic of China. These product series represent specialized hose technologies developed for different industrial applications, enabling customers to select optimized solutions based on operating media, pressure requirements, environmental conditions, and industry standards.
